Waste tank leak

[Cleanworks]

Tearing apart my back up van today. Hydramaster cds 4.2. have a small leak in the waste tank but what a nightmare to remove it. Control panel, heater exchangers and water box all attached to the waste tank. Have to disconnect and reconnect it all. Have to say, the tank lasted 24 years before having a leak. Can only find one so far, leak testing it now. Will patch it and it should be good for another 24 years. At the same time, I can service the pump, blower and shaft.



[hogjowl]

Can’t tell from the pictures, is the leak on the floor?



[Cleanworks]

Can’t tell from the pictures, is the leak on the floor?

Yes, tank is upside down. The leak is where they welded the flange that bolts to the floor. There are a couple of places where it looks weak. Thinking to fibreglass the bottom. My Cleanco was much easier to remove. Much better design.



[hogjowl]

Jimmy repaired his Cleanco waste tank by pouring in SOMETHING and letting it dry. He’d have to tell you what it was.



[Cleanworks]

Jimmy repaired his Cleanco waste tank by pouring in SOMETHING and letting it dry. He’d have to tell you what it was.

Yeah, is was a flex seal product. This hole is too big for that, it would just leak out. Once I fix it, I would be tempted to try Jimmy's solution to prevent further leaks. Here is a pic of the unit dismantled.



[BIG WOOD]

did you put that spray foam mess all over that coolant heat exchanger?



[Dolly Llama]

I've used this for repair
Got a couple years out of it.
Finally pulled the tank fiberglassed the bottom


..L.T.A.



[Cleanworks]

did you put that spray foam mess all over that coolant heat exchanger?

Yes. The original foam covering was messed up. This works better although it looks ugly. You don't see it when it's altogether.



[Cleanworks]

View attachment 126850



I've used this for repair
Got a couple years out of it.
Finally pulled the tank fiberglassed the bottom


..L.T.A.

I just used fibre cloth and polyester resin. May add a second layer tomorrow.



[AlienAgent]

Maybe next time drill it out, then thread a bolt with the threads coated thick with JB Weld into the hole? Apply a little more all around the head, then paint?



[Cleanworks]

Maybe next time drill it out, then thread a bolt with the threads coated thick with JB Weld into the hole? Apply a little more all around the head, then paint?

It's more than just one hole. The area adjacent to the weld is weak. I put a layer of fibreglass cloth down in a bed of resin and spread more resin on top. I think I'll do a second layer today just to be on the safe side.



[AlienAgent]

@Cleanworks that’ll work for sure. I kinda wondered about the bond between the fiberglass patch and the metal over time. It’ll probably last a lifetime though, I’m sometimes prone to overkill.



[hogjowl]

I’m sometimes prone to overkill.

You’re aware of the rubber room right?



[AlienAgent]

You’re aware of the rubber room right?

My mother in law spent some time in one 30 years ago.



[Cleanworks]

@Cleanworks that’ll work for sure. I kinda wondered about the bond between the fiberglass patch and the metal over time. It’ll probably last a lifetime though, I’m sometimes prone to overkill.

Just put everything back together today. The firbeglass cured beautifully overnight. Looks nice and strong. Should last until the life of this van which is maybe another 4-5 years. Hey, no leftover parts.



[Dolly Llama]

Maybe next time drill it out

been my experience with aluminum waste tanks, Joe, when a leak sprouts, the area around it is pitted and not long to spew too
Put a big bandaid on it

..L.T.A.



[Cleanworks]

been my experience with aluminum waste tanks, Joe, when a leak sprouts, the area around it is pitted and not long to spew too
Put a big bandaid on it

..L.T.A.

That was the case with my Cleanco. We welded sheet aluminum to it.



[sassyotto]

had a leak at the bottom of an aluminum tank once. Ground it down to the metal, drilled the hole round and plugged it with a bolt. Poured three layers of Flex Seal. No issues.

Since then, when buying new TMs, bottom 6 inches of waste tanks have been coated with Flex Seal

youd think they would come from the factory that way.



[Jimmy L]

FLEX SEAL !
BUY IT AND USE WHAT'S LEFT OVER TO GLUE YOUR DENTURES IN!

LOOZERS ALL!



[hogjowl]



[Cleanworks]

FLEX SEAL !
BUY IT AND USE WHAT'S LEFT OVER TO GLUE YOUR DENTURES IN!

LOOZERS ALL!

Use the white one for your dentures.



[BIG WOOD]

The new company that’s coming out with a new tm has a stainless steel frame and maybe tank next year

Oh shhh, I wasn’t supposed to tell anyone.



[hogjowl]

Nobody pays any attention to you anyway
